dry pack tile adheisve bonding glue mortar mixer machine
Introductions-dry pack tile adheisve bonding glue mortar mixer machine
Ceramic tile adheisve and tile bonding glue mortar mixer machine is also called as ceramic tile adhesive mixer machine, ceramic tile mortar producing machine, tile glue mixer, tile fixing bonder mix plant or tile bonding mortar production line, it is usally a completely full production line include the mixer machine, materials storage, transporting, batching&weighing, end product packing equipent, according to different output capacity, it can be classified simple small manual, semi-automatic,automatic and complete full automatic level mode for producting ceramic tile adhesive, tile mortar, tile glue, tile fixing bonder. Different output capacity and automatic level Ceramic tile adheisve and tile bonding glue mortar mixer machine, the mixer, materials feeding, batching& weighing, and packing process can be very different.
1. Simple small manual easy operated Ceramic tile adheisve and tile bonding glue mortar mixer machine
Simple small manual easy operated Ceramic tile adheisve and tile bonding glue mortar mixer machine is a classic and practical solution for initiation investmetn of small capacity Ceramic tile adheisve and tile bonding glue mortar factory, it is normally includes a mulity ribbon mixer which capacity can be from 1-5 ton per batch, 2 screw conveyors, 1 end product hopper, 1-2 packing machines and control cabinet.
Main parameters of Simple small manual easy operated Ceramic tile adheisve and tile bonding glue mortar mixer machine
Model | Mixer volume | Capacity | Total power | Occupation area | Height | Worker required |
Simple Dry Mortar Production Line |
TLN1000 (horizontal ribbon) | 3300*1050*2100(mm) | 1-3t/h | 17kw | 15m² | 3.2m | ≥3 |
TLN1500 (horizontal ribbon) | 3300*1050*2100(mm) | 3-4t/h | 20.5kw | 15m² | 3.2m | ≥3 |
TLN2000 (horizontal ribbon) | 3680*1200*2200(mm) | 4-5t/h | 24.5kw | 20m² | 3.2m | ≥3 |
2. Semi automatic Ceramic tile adheisve and tile bonding glue mortar mixer machine
Semi automatic Ceramic tile adheisve and tile bonding glue mortar mixer machine is mainly composed of non gravity twin shafts paddle mixer (with fly cut), finished product hopper, packaging machine, bucket elevator, dust collector, air compressor system, control system, etc. Semi automatic Ceramic tile adheisve and tile bonding glue mortar mixer machineis is suitable for ouput capacity not more than 15 t/h production plant and cement come in bags.
Main parameters of Semi automatic Ceramic tile adheisve and tile bonding glue mortar mixer machine
Model | Mixer volume | Capacity | Total power | Occupation area | Height | Worker required |
Semi automatic Ceramic tile adheisve and tile bonding glue mortar mixer machine
|
TLH2000 | 2m3 | 5-8t/h | 50-60kw | 30m² | 6.5m | ≥3 |
HTTN3000 | 3m3 | 10-15t/h | 60-80kw | 50-60m² | 9.5m | ≥4 |
HTTN4000 | 4m3 | 15-20t/h | 100-150kw | 80-100m² | 10.5m | ≥4 |
3. Automatic Ceramic tile adheisve and tile bonding glue mortar mixer machine
Automatic Ceramic tile adheisve and tile bonding glue mortar mixer machine is mainly composed of efficient mixing system, raw materials storing system, conveying system, lifting system, weighing system, premix system, packaging systems, dust removal system, material level control system, pneumatic system, automatic control system. Automatic dry mortar premixed mortar plant with annual output of 200,000 tons is mainly produce the for producting ceramic tile adhesive, tile mortar, tile glue, tile fixing bonder by mixing sand, cement, fly ash, cellulose, and additives together.
Main parameters of Automatic Ceramic tile adheisve and tile bonding glue mortar mixer machine
Model | Mixer volume | Capacity | Total power | Occupation area | Height | Worker required |
Automatic Ceramic tile adheisve and tile bonding glue mortar mixer machine |
HTTN2000 | 2m3 | 10-15t/h | 100-120kw | 120-180m² | 16m | ≥4 |
| HTTN3000 | 3m3 | 20-25t/h | 120-150kw | ≥150m² | 17m | ≥4 |
HTTN4000 | 4m3 | 25-30t/h | 120-200kw | ≥200m² | 18m | ≥4 |
Henan as one of the best Ceramic tile adheisve and tile bonding glue mortar mixer machine manufacturer in Zhengzhou of China, we can ddesign the most suitable solution as your actual deamnd of production capacity and budget, meanwhile, the formula and chemical addtives are also available, contact our engineer and sales now to get a cheap quotation and design solution for your Ceramic tile adheisve and tile bonding glue mortar mixer machine....
